Key Features:
Magnetic Hanger for easy one-handed operation.
True RMS AC + DC measurements.
Large easy-to-read LCD with backlight.
Auto/Manual Ranging.
Auto Power Off to conserve battery.
Measures up to 10 A (AC & DC).
Resistance up to 66 Mohm and Capacitance up to 66 mF.
Frequency counter up to 66 MHz.
Diode and continuity tests.
Features Comparison for Tool Kit Series Models:
| Features | 2712 | 2709B | 2708B | 2707B | 2706B | 2705B | 2704C | 2703C |
| Ranging | Auto/Manual | Auto/Manual | Auto/Manual | Manual | Manual | Auto/Manual | Manual | Manual |
| True RMS AC + DC | ✓ | ✓ | – | – | – | – | – | – |
| Current | 10 A AC/DC | 10 A AC/DC | 10 A AC/DC | 10 A AC/DC | 200 mA AC/DC | 10 A AC/DC | 10 A AC/DC | 10 A DC |
| Capacitance Measurement | to 40 uF | to 66 mF | – | to 20 uF | to 20 mF | – | to 20 uF | – |
| Transistor Test | – | – | ✓ | – | – | ✓ | – | – |
| Frequency Counter | to 500 kHz | to 66 MHz | – | to 20 MHz | to 40 kHz | – | to 20 MHz | – |
| Temperature Probe | – | – | ✓ | – | – | – | – | – |
| Logic Probe | – | – | ✓ | – | – | ✓ | – | – |
| Backlight LCD | ✓ | ✓ | – | – | ✓ | – | – | – |
| Analog Bar Graph | ✓ | – | ✓ | – | – | – | – | – |
| Battery Test | – | – | – | – | – | – | ✓ | – |
| Auto Power Off | ✓ | ✓ | ✓ | – | ✓ | ✓ | – | – |
