Key Features:
Accurate Voltage Stabilization: MTE’s High-Frequency Guardian Filters deliver precise and stable voltage output, mitigating the risk of equipment damage and downtime in high-frequency environments.
Wide Current Range: Choose from a comprehensive range of current options (80A to 600A) to match the specific requirements of your high-frequency systems.
Durable Construction: Crafted to withstand demanding conditions and high-frequency operations, guaranteeing long-lasting reliability and performance.
Modular Design: The modular configuration offers flexibility and ease of installation, making it suitable for a variety of high-frequency setups.
Customizable Solutions: Tailor the Guardian Filters to your unique voltage stabilization needs with configurable options and setups.
Applications:
High-Frequency Machinery: Ensure precise voltage levels for high-frequency machinery and equipment, optimizing performance and durability.
Telecommunications: Maintain stable power supply for critical telecommunications systems, protecting against voltage fluctuations.
Broadcasting: Ensure uninterrupted operation of broadcasting equipment by stabilizing voltage at high frequencies.
Medical Equipment: Protect sensitive medical equipment from voltage variations, ensuring patient safety and continuous operation.
Why Choose Us?
Proven Performance: MTE’s filters are renowned for their reliability, durability, and consistent performance in high-frequency applications.
Tailored Solutions: Customized solutions are available to meet the unique voltage stabilization requirements of high-frequency systems, ensuring optimal functionality.
Technical Expertise: Leverage our technical support and expertise to select the right high-frequency filter for your specific application needs.
| 380V | 480V | Filter | Part | Weight | Filter Dimensions | Watts | Capacitor/Capacitor Panel Assembly | |||
| Motor | Motor | Amps | Number | (H x W x D) | Loss | Dimensions (H x W x D) | ||||
| KW | HP | Rating | Lbs | Kgs | Inches | Millimeters | Inches | Millimeters | ||
| 37 | 60 | 80 | SWGM0080D-HF05300 | 62 | 28 | 10.5 X 12.0 X 9.1 | 267 x 305 x 231 | 360 | 5.8 X 16.3 X 7.6 | 147 x 414 x 193 |
| 55 | 75 | 110 | SWGM0110D-HF05300 | 78 | 35 | 10.1 X 12.0 X 10.1 | 257 x 305 x 257 | 451 | 5.8 X 16.3 X 7.6 | 147 x 414 x 193 |
| – | 100 | 130 | SWGM0130D-HF05300 | 92 | 42 | 10.2 X 12.0 X 11.5 | 259 x 305 x 292 | 504 | 5.8 X 16.3 X 7.6 | 147 x 414 x 193 |
| 75 | 125 | 160 | SWGM0160D-HF05300 | 96 | 44 | 10.0 X 12.0 X 11.6 | 254 x 305 x 295 | 563 | 5.8 X 16.3 X 7.6 | 147 x 414 x 193 |
| 110 | 150 | 200 | SWGM0200D-HF05300 | 136 | 62 | 12.1 X 15.3 X 11.2 | 307 x 389 x 284 | 718 | 6.7 X 16.3 X 7.6 | 170 x 414 x 193 |
| 132 | 200 | 250 | SWGM0250D-HF05300 | 143 | 65 | 12.3 X 15.3 X 11.3 | 312 x 389 x 287 | 911 | 6.7 X 16.3 X 7.6 | 170 x 414 x 193 |
| 160 | 250 | 305 | SWGM0305D-HF05300 | 174 | 79 | 12.4 X 15.3 X 12.6 | 315 x 389 x 320 | 958 | 6.7 X 16.3 X 7.6 | 170 x 414 x 193 |
| 220 | 350 | 415 | SWGM0415D-HF05300 | 244 | 111 | 12.3 X 15.3 X 14.3 | 312 x 389 x 363 | 1144 | 6.7 X 16.3 X 7.6 | 170 x 414 x 193 |
| 280 | 450 | 515 | SWGM0515D-HF05300 | 258 | 117 | 14.2 X 15.3 X 13.1 | 361 x 389 x 333 | 1250 | 6.7 X 16.3 X 7.6 | 170 x 414 x 193 |
| 335 | 500 | 600 | SWGM0600D-HF05300 | 306 | 139 | 14.3 X 15.3 X 14.3 | 363 x 389 x 363 | 1321 | 6.7 X 16.3 X 7.6 | 170 x 414 x 193 |
