IRFrms rms converter module

IRFrms RMS Converting AC Transducer

RMS Converter Transducers for AC to DC or AC+DC to DC Proportional Output

The IRFrms is an instantaneous to true RMS converter, offering high precision in converting AC or AC+DC signals into an isolated DC signal that represents the true RMS value. It matches the performance of high-end true RMS voltmeters, providing scalable outputs for voltage or 4-20mA current loops, with options for isolated or non-isolated configurations.

Applications:

Typically used with voltage output current probes, current shunts, and current transformers.
Ideal for delivering isolated signals for connection to computers, data loggers, or SCADA systems.
Can be configured to work with most current probes, sensors, and data loggers.
Suitable for high voltage applications (up to 1000V) using model VTHR.
Provides both RMS and instantaneous outputs for enhanced diagnostic and metering capabilities.

Key Features:

True RMS Conversion: Converts AC or AC+DC signals to DC output.
RMS and Instantaneous Outputs: Allows current probes and CTs to have both outputs for diagnostics and metering.
High Voltage Isolation: Input/output isolation up to 1000V peak with the Iso option.
Wide Input and Output Range:
Input Ranges: 2mV to 240V (user-specified input range).
Output Options: 0-100mV, 0-1V, 0-5V, 0-10V, 0-20mA, 4-20mA, and 4-12-20mA.
Wide Bandwidth: DC-50kHz for non-isolated applications, making it suitable for high-frequency applications.
Power Supply Flexibility: Powered from 5Vdc-125Vdc and 90-240Vrms AC, ensuring compatibility with a wide range of systems.
High Accuracy: 1% accuracy from 120% to 5% of the range, ensuring reliable and precise measurements.
Fused Input and Output Protection: Protects both the input and output circuitry, ensuring long-term reliability.

Specifications:

Bandwidth: DC to 50kHz (non-isolated).
Input/Output Isolation: Up to 1000Vpk with the isolated version (Iso option).
Input Impedance: 50 ohms, 100kohms, or 1Mohm (user-specified).
Output Impedance: 100 ohms (50 ohms optional).
Input Ranges: From 2mV to 240V (user-specified).
Operating Temperature: -20°C to +60°C.
Power Supply:
5V, 12V, 24V, 48V, 110Vdc.
110Vac or 230Vac options.
Mounting: Supplied with DIN rail mountings.
Certification: CE Marked, UL-approved materials throughout.

Output Options:

DC Outputs:
0-100mV
0-1V
0-5V
0-10V
0-20mA
4-20mA
4-12-20mA

Part Numbering Examples:

Non-Isolated Version:
Input: 2Vrms, Output: 0-10Vdc, AC+DC coupled, 24Vdc power.
Part No.: IRFrms / 2 / ac+dc / 10 / 24Vdc.

Isolated Version:
Input: 110Vrms, Output: 0-5Vdc, Isolated, AC coupled, 24Vdc power.
Part No.: IRFrms-iso / 110 / ac / 5 / 24Vdc.

Applications:

Voltage output current probes.
Current shunts.
Current transformers.
Diagnostic systems: Providing instantaneous and RMS output for enhanced system diagnostics.
Process control and status alarming for AC/DC systems.

The IRFrms RMS converter transducers are versatile, capable of transforming AC or AC+DC inputs into isolated, scalable DC signals for a wide range of industrial and commercial applications, including power metering, data acquisition, and process control.

CE marked and built with UL-approved materials for safety and compliance with international standards.
