Key Features & Benefits:
4.3-Inch Color Touch Screen: Allows for a clear and intuitive display of measurement results.
4-Wire Kelvin Test Leads: Included for highly accurate, low-resistance measurements.
Low Power Resistance Mode: Protects devices under test (DUT) by reducing the potential impact of high current during testing.
Fast Measurement Speed: Up to 20 ms/reading to support high-throughput manufacturing environments.
Bin Sorting with Statistical Measurement: Enables sorting and statistical evaluation of components.
Screen Capture: Save screenshots directly to a USB drive for documentation and analysis.
Multiple Interfaces:
RS232 and USB (both USBTMC and virtual COM).
LAN Interface (available on the 2841 model only) for remote control and data acquisition.
Models:
Model 2840:
Ideal for general-purpose DC resistance measurements.
Includes RS232 and USB interfaces.
Model 2841:
Adds temperature correction capability, making it suitable for applications where temperature compensation is critical for accurate resistance measurements.
Includes LAN interface in addition to RS232 and USB.
Applications:
Contact Resistance Measurements: Suitable for relays, switches, and PCB traces.
Low Power Testing: Ensures the protection of sensitive components during resistance testing.
Automated Testing: Can be easily integrated into automated test systems for high-volume testing.
Component Sorting: Equipped with bin-sorting and statistical analysis features to streamline component evaluation.
The 2840 Series DC Resistance Meters are designed for precision, speed, and ease of use, making them perfect for both R&D and production environments.
