Key Features:
Input Ranges: 100mA / 200mA / 1A / 2A / 5A / 10A RMS AC or DC, operational from 10% to 125% of range
Output Options:
50mV, 100mV, 1V, 5V, 10V
4-20mA (DC current input only)
4-12-20mA (ATHR models for true RMS conversion)
Auxiliary Power Input: 5V / 9-36V / 48V / 110V / 230V DC or AC
Max current draw: 50mA (24VDC)
Fast Response Time: <200us (without filtering)
Frequency Range: DC to 10kHz
Accuracy: Better than 1.0% at +23°C ±5°C, traceable to NIST/NPL
Internal Gain Calibration Controls: For precision adjustments
Isolation Amplifier: Rated for 1.5kV
Temperature Range:
Working: 0°C to +50°C
Functional: -10°C to +70°C
Rated Insulation: 1.5kVpk (flash tested 2.5kV for 1 minute)
Connections: Screw terminal input/output connections (IP30)
Mounting: 3.5mm fixing holes for easy installation
Compliance:
CE Marked
UL94V0, IEC1010 Cat II, IEC348, DIN 57411
Enclosure: IP50 case, terminals rated IP30, complies with IEC529
Safety and Operating Guidelines:
Ensure proper training for personnel handling ATH transducers to prevent electrical hazards.
Switch off and isolate the test circuit before making any connections.
Use safety-rated cables with proper insulation for all connections to avoid human contact.
Ground the ATH output (LO terminal) correctly to prevent errors or hazards.
Verify that maximum input-to-output isolation ratings are not exceeded.
Protect circuits with over-current protection devices.
Do not apply mechanical stress to ATH terminals during installation.
Operate the ATH transducer only with the case closed.
Store and use the transducer in clean and dry environments, free from explosion risks.
Applications:
Energy Metering: For precise current monitoring in energy distribution systems.
Industrial Control: Suitable for monitoring current in AC/DC drives and other process control systems.
Rail Transportation: Used in current measurement for rail systems.
Process Control: Monitors currents in manufacturing and industrial operations.
Circuit Breaker Trip Coils: Ensures accurate current measurement for circuit protection systems.
SCR Current Measurement: For thyristor-based systems.
Fault Detection in Electrical Systems: Monitors fault currents in various electrical systems such as steam turbines, substations, and power transmission systems.
Additional Applications:
Current Sensing: For phase meters, V-A indicators, Cos Phi indicators, and power factor meters.
Wideband Power Meters: Suitable for use in wideband watt meters and power analysis tools.
High-Frequency Watt Meters: Can be used for precision high-frequency power measurement.
Calibration: For current transformer calibration, current probe phase delay measurement, and SCR measurements.
Automotive and Electric Vehicles: Used in automotive alternator measurements and chopper current control in electric vehicles.
Testing and Fault Detection: Used in three-phase fault testing, modulator fault detection, and laser system current measurements.
The ATH current transducers are available in various configurations, supporting a wide range of current inputs and outputs, including 4-20mA and voltage options. They are also compatible with different power input types and offer calibration certificates traceable to NIST (USA) and NPL (UK).
For reliable and accurate current sensing across multiple industries, the ATH current transducer range is a versatile and essential tool for precision measurements and control.
